HPE ProLiant DL380 Gen10 for Cohesity DataPlatform – rack-mountable – Xeon

Cache Memory
Type :L3 cache
Per Processor Size :22 megabyte, 22 megabyte
Installed Size :44 megabyte

RAM
Form Factor :DIMM 288-pin
Technology :DDR4 SDRAM
Installed Size :128 GB
Max Supported Size :1.5 TB
Configuration Features :4 x 32 GB
Data Integrity Check :Advanced ECC
Slots Qty :24
Empty Slots :20
Memory Speed :2666 megahertz
Rated Memory Speed :2666 megahertz
Features :Registered

Type :RAID
Interface Type :Serial ATA-600 / SAS 3.0
Storage Controller Name :HPE Smart Array P408i-a
Channel Qty :8
Installed Qty :1
Buffer Size :2 GB, 2 GB
RAID Level :RAID 0, RAID 1, RAID 1 ADM, RAID 10, RAID 10 ADM, RAID 5, RAID 50, RAID 6, RAID 60

Networking
Remote Management Controller :Integrated Lights-Out 5
Data Link Protocol :10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Ports :4 x Gigabit Ethernet
Remote Management Protocol :IPMI 2.0, SMASH CLP, SNMP 3
Features :PXE support, Wake on LAN (WoL)

Expansion Bays
Bays :1 (total) / 1 (free) x external Universal Media Bay, 12 (total) / 0 (free) x hot-swap 3.5″ LFF

Expansion Slots
Slots :1 (total) / 1 (free) x FlexibleLOM, 1 (total) / 1 (free) x microSD Card (internal), 1 (total) / 1 (free) x PCIe 3.0 x16 – half-length, full-height, 2 (total) / 2 (free) x PCIe 3.0 x8 – half-length, full-height

Interface Provided
Interfaces :1 x HPE iLO – RJ-45 (1 rear), 1 x HPE iLO – Type A (1 in front), 1 x VGA (1 rear), 4 x LAN (10Gigabit Ethernet) – RJ-45 (4 rear), 5 x USB 3.0 (1 front, 2 rear, 2 internal)

Power Device
Type :Power supply – hot-plug
Power Redundancy :Optional
Power Redundancy Scheme :1+1 (with optional power supply)
Installed Qty :2
Max Supported Qty :2
Power Provided :800 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
Efficiency :94%
80 PLUS Certification :80 PLUS Platinum

Service & Support Details
Service & Support :Limited warranty – parts and labor – 3 years – on-site – response time: next business day
