Is your secondary data and applications, including backups, disaster recovery, files, objects, test/dev, archives, and analytics massively fragmented across a complex patchwork of specialized point products and infrastructure silos in your data center and the cloud? As secondary data often gets copied more than 10X across distinct silos with no central visibility and control [1], it is inefficient and costly to manage, and this creates a crippling source of compliance risk. HPE Solutions for Cohesity DataPlatform helps customers simply and efficiently protect, store, and manage this exponentially growing secondary data across clouds, data centers, or remote/branch offices, and put it to work for their business. HPE Solutions for Cohesity DataPlatform are built on the HPE ProLiant DL380 Gen10 server or the HPE Apollo 2000 Gen10 system.
Chassis
Form Factor :Rack-mountable
Manufacturer Form Factor :Rack-mountable
Server Storage Bays :Hot-swap
Server Swappable Drive Form Factor :3.5″
Server Swappable Drive Form Factor (metric) :8.9 cm
Server Swappable Drive Interface :SAS
Hot-Swap Bays Qty :12
Built-in Devices :LED panel
Processor
Type :Xeon Gold
Number of Cores :16-core
Processor Number :6143
Installed Qty :2
Max Supported Qty :2
Server Scalability :2-way
Upgradability :Upgradable
Manufacturer :Intel
Clock Speed :2.8 GHZ
Max Turbo Speed :4 GHZ
Processor Main Features :Hyper-Threading Technology, Intel Turbo Boost Technology 2
Cache Memory
Type :L3 cache
Installed Size :44 megabyte
RAM
Form Factor :DIMM 288-pin
Technology :DDR4 SDRAM
Installed Size :128 GB
Max Supported Size :1.5 TB
Configuration Features :4 x 32 GB
Data Integrity Check :Advanced ECC
Slots Qty :24
Empty Slots :20
Memory Speed :2666 megahertz
Rated Memory Speed :2666 megahertz
Features :Registered
Type :RAID
Interface Type :Serial ATA-600 / SAS 3.0
Storage Controller Name :HPE Smart Array P408i-a
Channel Qty :8
Installed Qty :1
Buffer Size :2 GB
RAID Level :RAID 0, RAID 1, RAID 1 ADM, RAID 10, RAID 10 ADM, RAID 5, RAID 50, RAID 6, RAID 60
Networking
Remote Management Controller :Integrated Lights-Out 5
Data Link Protocol :10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Ports :4 x Gigabit Ethernet
Remote Management Protocol :IPMI 2.0, SMASH CLP, SNMP 3
Features :PXE support, Wake on LAN (WoL)
Expansion Bays
Bays :1 (total) / 1 (free) x external Universal Media Bay, 12 (total) / 0 (free) x hot-swap 3.5″ LFF
Expansion Slots
Slots :1 (total) / 1 (free) x FlexibleLOM, 1 (total) / 1 (free) x microSD Card (internal), 1 (total) / 1 (free) x PCIe 3.0 x16 – half-length, full-height, 2 (total) / 2 (free) x PCIe 3.0 x8 – half-length, full-height
Interface Provided
Interfaces :1 x HPE iLO – RJ-45 (1 rear), 1 x HPE iLO – Type A (1 in front), 1 x VGA (1 rear), 4 x LAN (10Gigabit Ethernet) – RJ-45 (4 rear), 5 x USB 3.0 (1 front, 2 rear, 2 internal)
Power Device
Type :Power supply – hot-plug
Power Redundancy :Optional
Power Redundancy Scheme :1+1 (with optional power supply)
Installed Qty :2
Max Supported Qty :2
Power Provided :800 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
Efficiency :94%
80 PLUS Certification :80 PLUS Platinum
Service & Support Details
Service & Support :Limited warranty – parts and labor – 3 years – on-site
