Ruckus ICX 7650-48F - switch - 48 ports - managed - rack-mountable

Ruckus ICX 7650-48F – switch – 48 ports – managed – rack-mountable

(ICX7650-48F-E2)

Ruckus innovates across wired technologies, as well as wireless, to enable awesome customer experiences. The Ruckus ICX family of fixed form-factor switches work together to simplify network setup and management, enhance security, minimize troubleshooting and make upgrades easy.

Main Features

48F
managed
front to back airflow
Switch
24 x 1 Gigabit / 10 Gigabit SFP+ + 24 x Gigabit SFP + 4 x QSFP
rack-mountable

Product Specifications

Header

ManufacturerRuckus Wireless

BrandRuckus

Product LineRuckus ICX

Model7650-48F

Packaged Quantity1

Chassis

Airflow DirectionFront to back airflow

RAM

Installed Size4 GB

Flash Memory

Installed Size16 GB, 16 GB

Performance

PerformanceAggregate stacking bandwidth: 2.4 Tbps, Forwarding capacity: 839 Mpps, Switching capacity: 1.128 Tbps

Capacity

CapacityIPv4 routes: 128000, IPv6 routes: 7000, Multicast groups: 8192, Next hop address: 12000, Ports per trunk group: 16, PVLANs supported: 256, QoS queues: 10, Trunk groups: 256, Virtual Routing and Forwarding (VRF) instances: 50, VLANs supported: 4095

Networking

TypeSwitch

SubcategoryNetwork hubs and switches

SubtypeGigabit Ethernet

Form FactorRack-mountable

StackableStackable

Ports Qty48

Routing ProtocolBGP for IPv6, BGP-4, BGP-4+, ECMP, GRE, MSDP, OSPF for IPv6, OSPFv2, OSPFv3, Policy-based routing (PBR), RIP-1, RIP-2, RIPng, Static IPv4 routing, Static IPv6 routing, VRRPE, VRRPv3

MAC Address Table Size80K entries

Jumbo Frame Support9216 bytes

ManageableYes

Remote Management ProtocolCLI, HTTP, HTTPS, SNMP 1, SNMP 2c, SNMP 3, Telnet, TFTP

Features2 fans, 5MB packet buffer, 802.1x authentication, Auto-uplink (auto MDI/MDI-X), Class of Service (CoS), DHCP snooping, DiffServ support, Dynamic ARP Inspection (DAI), Encapsulated Remote SPAN (ERSPAN), Front to back airflow, GARP VLAN Registration Protocol (GVRP), IGMP fast leave, IGMP proxy, IGMP snooping, Link Fault Signaling (LFS), Loopback detection, MAC address filtering, Metro Ring Protocol (MRP) support, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, NTP time synchronization, Per-VLAN Rapid Spanning Tree (PVRST), Per-VLAN Spanning Tree (PVST), Per-VLAN Spanning Tree Plus (PVST+), PIM-SM snooping, Port mirroring, Priority-based flow control, Remote Fault Notification (RFN), Root Guard, Secure Copy (SCP), sFlow, Strict Priority (SP), Uni-Directional Link Detection (UDLD), Virtual Cable Test (VCT) technology, Virtual Switch Redundancy Protocol (VSRP) support, VLAN support, Weighted Round Robin (WRR)

Compliant StandardsIEEE 802.1ab (LLDP), IEEE 802.1ae, IEEE 802.1AX, IEEE 802.1BR, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

Ports

Qty24

Ports (2nd)

Qty24

TypeGigabit SFP

Ports (3rd)

Qty4

TypeQSFP

Power Device

TypeInternal power supply

Hot-PlugHot-plug

Power RedundancyYes

Power Redundancy Scheme1+1

Installed Qty2

Max Supported Qty2

Power Provided250 watt

Nominal VoltageAC 120/230 V

Frequency Required50/60 hertz

Power Consumption Operational216 watt

Miscellaneous

Color CategoryBlack

Height (Rack Units)1

Encryption AlgorithmAES

Authentication MethodRADIUS, Secure Shell v.2 (SSH2), TACACS, TACACS+

MTBF243,130 Hours

Compliant StandardsAS/NZS 55022, CSA C22.2 No. 60950-1-07, EN 55022/CISPR 22 Class A, EN 60825-1, EN 60950-1:2006, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-1, EN 61000-6-3, EN55024, FCC Class A certified, IEC 60950-1, IEC 68-2-27, IEC 68-2-32, IEC 68-2-36, IEC 68-2-6, RoHS 6/6, UL 60950-1, VCCI Class A, WEEE

Dimensions & Weight

Width17.3 inch

Depth16 inch

Height1.7 inch

Weight16.75 lbs

Environmental Parameters

Min Operating Temperature32 degree Fahrenheit

Max Operating Temperature113 degree Fahrenheit

Min Storage Temperature-40 degree Fahrenheit

Max Storage Temperature158 degree Fahrenheit

Humidity Range Operating10 – 90% (non-condensing)

Humidity Range Storage5 – 95% (non-condensing)
